Morris Xpress Double Disc 40'
Contents:
Frame Widths
| Transport Length | 35.01 ft in (10.67 m) |
| Transport Width | 13.85 ft in (4.22 m) |
| Transport Height | 9.52 ft in (2.9 m) |
| Inner Wing | 17.84 ft in (5.44 m) |
| Main Frame | 10.13 ft in (3.09 m) |
Base Size
| Base Width | 40 ft in (12.2 m) |
| Minimum Ground Clearance | 8 in (20.3 cm) |
Working Width
| 7.5 In Spacing | 40 ft in (12.2 m) |
| 10 In Spacing | 40 ft in (12.2 m) |
Number Of Shanks
| 7.5 In Spacing | 64 |
| 10 In Spacing | 48 |
Weights
| 7.5 In Spacing | 21710 lb (9847.5 kg) |
| 10 In Spacing | 19746 lb (8956.7 kg) |
Tires
| Main Frame Casters | (4) 12.5Lx15FI load range F 8 bolt hub |
| Inner Wing Casters | (4) 9.5Lx15SL |
| Outer Wing Casters | (4) 9.5Lx15SL |
