John Deere 350C
Browse All John Deere or Articulated Dump Truck Models
Contents:
Dimensions
| Overall Length | 34.5 ft in (10545 mm) |
| Overall Width | 10.58 ft in (3200 mm) |
| Overall Height | 11.92 ft in (3631 mm) |
| Wheelbase | 14.67 ft in (4474 mm) |
| Ground Clearance | 1.87 ft in (569 mm) |
| Dump Height | 22.83 ft in (6950 mm) |
| Dump Ground Clearance | 2.51 ft in (765 mm) |
Dump
| Dump Angle | 70 degrees |
| Lower Time | 10 sec |
| Rated Payload | 70547 lb (32000 kg) |
| Capacity - Struck | 19.61 yd3 (15 m3) |
| Raise Time | 19 sec |
| Capacity - Heaped | 25.6 yd3 (19.61 m3) |
Engine
| Engine Make | 2346 |
| Engine Model | OM442A |
| Gross Power | 345 hp (257.3 kw) |
| Net Power | 335 hp (249.9 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1184 lb ft (1605.3 Nm) |
| Torque Measured @ | 1000 rpm |
| Aspiration | Turbocharged |
| Displacement | 892 cu in (14.7 L) |
Operational
| Fuel Capacity | 106 gal (400 L) |
| Hydraulic System Fluid Capacity | 36.9 gal (140 L) |
| Cooling System Fluid Capacity | 8.9 gal (34 L) |
| Engine Oil Capacity | 8.9 gal (34 L) |
| Transmission Fluid Capacity | 7.3 gal (28 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
| Tire Size | 26.5R25 |
Transmission
| Transmission Type | Allison HD4560 engine mounted automatic planetary, hydraulically actuated multiple-disc clutches, electronic control over hydraulic actuation, hydrodynamic torque converter with lock |
| Number Of Forward Gears | 5 |
| Number Of Reverse Gears | 1 |
| Max Speed | 31 mph (50 km/h) |
Weights
| Center Axle - Empty | 15058 % |
| Front Axle - Empty | 29829 lb (13530 kg) |
| Rear Axle - Empty | 14396 lb (6530 kg) |
| Front Axle - Loaded | 42276 % |
| Center Axle - Loaded | 44108 % |
| Rear Axle - Loaded | 43446 lb (19707 kg) |
| Total Empty | 59282 lb (26890 kg) |
| Total Loaded | 129830 lb (58890 kg) |
