Link-Belt E30
Browse All Link-Belt or Articulated Dump Truck Models
Contents:
Dimensions
| Overall Length | 32.02 ft in (9758 mm) |
| Overall Width | 9.39 ft in (2860 mm) |
| Overall Height | 11 ft in (3350 mm) |
| Wheelbase | 17.91 ft in (5458 mm) |
| Ground Clearance | 1.59 ft in (484 mm) |
Dump
| Capacity - Struck | 17 yd3 (13 m3) |
| Capacity - Heaped | 21.6 yd3 (16.52 m3) |
| Rated Payload | 60000 lb (27215.55 kg) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | M11-C270 |
| Gross Power | 270 hp (201.4 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 910 lb ft (1233.8 Nm) |
| Torque Measured @ | 1500 rpm |
| Aspiration | Turbocharged and Aftercooled |
| Displacement | 661 cu in (10.9 L) |
Operational
| Fuel Capacity | 85.9 gal (325 L) |
| Hydraulic System Fluid Capacity | 52.9 gal (200 L) |
| Cooling System Fluid Capacity | 11.4 gal (43 L) |
| Engine Oil Capacity | 9 gal (34 L) |
| Transmission Fluid Capacity | 5.1 gal (19 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 amps |
| Tire Size | 23.5 R25 |
Transmission
| Transmission Type | Power Shift |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 3 |
| Max Speed | 30 mph (48.3 km/h) |
Weights
| Front Axle - Empty | 19841 lb (8999.8 kg) |
| Rear Axle - Empty | 19841 lb (8999.8 kg) |
| Total Empty | 39682 lb (17999.5 kg) |
| Total Loaded | 99208 lb (45000 kg) |
