Caterpillar BG210B
Browse All Caterpillar or Asphalt Paver Models
Contents:
Dimensions
| Length W/ Screed | 19.17 ft in (5842 mm) |
| Transport Width | 8.21 ft in (2502 mm) |
| Tire Size | 12x22 Solid Rubber, 14x24 |
Engine
| Engine Model | 3054DIT |
| Gross Power | 107 hp (79.8 kw) |
| Displacement | 244.1 cu in (4 L) |
Operational
| Operating Weight W/O Screed | 19369.9 lb (8786 kg) |
| Fuel Capacity | 50 gal (189 L) |
| Hydraulic System Fluid Capacity | 47.1 gal (178 L) |
| Cooling System Fluid Capacity | 5.1 gal (19 L) |
Hopper/Paver
| Paving Width - Std | 6 ft in (1828 mm) |
| Paving Width - Max | 16.1 ft in (4877 mm) |
| Paving Speed - Max | 275.3 ft/min (83.9 m/min) |
| Travel Speed - Max | 13.5 mph (21.7 km/h) |
| Auger Diameter | 14.1 in (357 mm) |
