Challenger LB44B
Browse All Challenger or Baler Models
Contents:
Baler Pickup
| Overall Width | 9.83 ft in (3 m) |
| Number Of Tines | 128 |
| Tine To Tine Width | 6.72 ft in (2.05 m) |
| Lift Type | hydraulic |
Dimensions
| Overall Length | 30.84 ft in (9400 mm) |
| Overall Width | 10.77 ft in (3280 mm) |
| Overall Height | 11.76 ft in (3582 mm) |
| Tractor Pto Power Required | 150 hp (111.86 kw) |
| Weight | 22741 lb (10315.15 kg) |
Bale Size
| Bale Height | 4.2 ft in (1275 mm) |
| Bale Width | 4 ft in (1200 mm) |
| Bale Length - Max | 9 ft in (2743 mm) |
Feeding Chamber
| Packer Type | Fork Type w/ 6 Hard Surfaced Tines |
| Stuffer Type | Fork Type |
Plunger
| Spm | 33 |
| Stroke Length | 32.8 in. |
| Bearing Type | 4 tapered roller bearings sealed, 2 ball bearing rollers sealed |
Wrapping System
| Twine Type | Six Double Knot Type |
| Twine Ball Capacity | 30 |
