Claas Quadrant 2200 R
Contents:
Baler Pickup
| Overall Width | 6.89 ft in (2.1 m) |
| Number Of Bars | 4 |
| Tine To Tine Width | 6.24 ft in (1.9 m) |
Dimensions
| Overall Width | 9.72 ft in (2960 mm) |
| Overall Height | 8.54 ft in (2600 mm) |
| Weight | 14991.44 lb (6800 kg) |
Bale Size
| Bale Length - Min | 1.7 ft in (500 mm) |
| Bale Height | 2.3 ft in (700 mm) |
| Bale Width | 4 ft in (1200 mm) |
| Bale Length - Max | 9.9 ft in (3000 mm) |
Feeding Chamber
| Packer Type | 3-phase cycle |
Plunger
| Spm | 51 |
Wrapping System
| Twine Type | 6 knotters |
| Twine Ball Capacity | 24 |
