Massey Ferguson 1844S
Browse All Massey Ferguson or Baler Models
Contents:
Baler Pickup
| Overall Width | 9.05 ft in (2.76 m) |
| Augers Shaft Size | 1.38 in (34.9 mm) |
| Augers Speed | 278 rpm |
| Gauge Wheels | 2 |
| Inside Width | 77.52 in (1969 mm) |
| Augers Length | 33.55 in (852 mm) |
| Pickup Protection | Slip & overrunning clutch |
| Tine Control | Dual camtracks |
| Tine Spacing | 2.6 in (66 mm) |
| Tine To Tine Width | 5.85 ft in (1.79 m) |
| Type Of Tines | Double tines |
| Number Of Tine Bars | 4 |
| Number Of Tines | 56 |
| Outer Tine-To-Tine Width | 91.23 in (2317 mm) |
| Pickup - Drive | Drive shaft and roller chain |
| Pickup Gauge Wheel | 4.00 x 16 pneumatic w/ inner tube |
| Pickup Lift | Hydraulic cylinder |
Dimensions
| Overall Width | 8.67 ft in (2642 mm) |
| Length W/Bale Chute | 285 in (7239 mm) |
| Height W/Shielding | 69.02 in (1753 mm) |
| Weight | 5705.57 lb (2588 kg) |
| Tractor Pto Power Required | 80.47 hp (60 kw) |
Bale Size
| Baler Weight | 8007.2 lb (3632 kg) |
Engine
| Electrical System | 12 V DC |
Bale Size
| Bale Length - Min | 1.1 ft in (305 mm) |
| Bale Length - Max | 4.4 ft in (1321 mm) |
| Bale Cross Section,Height X Width(In,Mm) | 15 x 22 (380 x 560) |
Tires
| Standard | 14L x 16.1 , 12 Ply |
Feeding Chamber
| Protection | Shearbolt |
| Stuffer Type | 6 Crank tines |
Hydraulic System
| Hydraulic System Type | Self-contained |
| Pump Displacement | 3.6 gal/min (13.6 L/min) |
Plunger
| Stroke Length | 21.9 in (556 mm) |
| Plunger Speed (Strokes/Min) | 90 |
