Massey Ferguson MF 187
Browse All Massey Ferguson or Baler Models
Contents:
Baler Pickup
| Overall Width | 8.73 ft in (2.66 m) |
| Number Of Bars | 4 |
| Number Of Tines | 120 |
| Tine To Tine Width | 7.32 ft in (2.23 m) |
| Lift Type | hydraulic cylinder |
Dimensions
| Overall Length | 29.57 ft in (9010 mm) |
| Overall Width | 9.75 ft in (2970 mm) |
| Overall Height | 11.65 ft in (3550 mm) |
| Tractor Pto Power Required | 120.7 hp (90 kw) |
| Weight | 17681.08 lb (8020 kg) |
Bale Size
| Bale Length - Min | 8.3 ft in (2500 mm) |
| Bale Height | 2.9 ft in (875 mm) |
| Bale Width | 4 ft in (1200 mm) |
Feeding Chamber
| Packer Type | fork type, 6 tine |
Plunger
| Spm | 42.7 |
| Stroke Length | 710mm |
| Bearing Type | sealed taper roller & ball |
Wrapping System
| Twine Type | double knot, twine tie, polypropylene or sisal |
| Twine Ball Capacity | 30 |
| Wire Coil Capacity | 6 |
