Massey Ferguson MF 1837
Browse All Massey Ferguson or Baler Models
Contents:
Baler Pickup
| Overall Width | 6.34 ft in (1.93 m) |
| Number Of Tines | 42 |
| Tine To Tine Width | 5.84 ft in (1.78 m) |
| Number Of Bars | 3 |
Dimensions
| Overall Length | 17 ft in (5180 mm) |
| Overall Width | 7.75 ft in (2360 mm) |
| Overall Height | 5.42 ft in (1650 mm) |
| Tractor Pto Power Required | 35 hp (26.1 kw) |
| Weight | 3049 lb (1383 kg) |
Bale Size
| Bale Length - Min | 1.1 ft in (305 mm) |
| Bale Height | 1.5 ft in (457 mm) |
| Bale Width | 1.2 ft in (356 mm) |
| Bale Length - Max | 4.4 ft in (1321 mm) |
Feeding Chamber
| Packer Type | Crank type, 4 tine |
Plunger
| Spm | 100 |
| Stroke Length | 550mm |
| Density Control | Spring loaded-rail |
| Bearing Type | Sealed ball bearing |
Wrapping System
| Twine Type | Twine Tie |
| Twine Ball Capacity | 4 |
