New Idea 7220
Contents:
Baler Pickup
| Overall Width | 7.6 ft in (2.32 m) |
| Number Of Tines | 56, Double Tines |
| Tine To Tine Width | 5.85 ft in (1.79 m) |
| Number Of Bars | 4 |
Dimensions
| Overall Length | 20.3 ft in (6187 mm) |
| Overall Width | 8.71 ft in (2652 mm) |
| Overall Height | 5.5 ft in (1676 mm) |
| Weight | 4376.18 lb (1985 kg) |
Bale Size
| Bale Length - Min | 1.1 ft in (305 mm) |
| Bale Height | 1.5 ft in (457 mm) |
| Bale Width | 1.4 ft in (406 mm) |
| Bale Length - Max | 4.4 ft in (1321 mm) |
Feeding Chamber
| Stuffer Type | Crank Type Cam Controlled w/ 3 Tines |
Plunger
| Spm | 100 |
| Stroke Length | 23 in. |
| Density Control | Hydraulic Density Control Rails |
| Bearing Type | Sealed Ball Bearing Rollers |
