Genie S80
Contents:
Dimensions
| Overall Length | 36.42 in (11100 mm) |
| Overall Width | 8.21 ft in (2500 mm) |
| Overall Height - Mast Lowered | 8.21 ft in (2500 mm) |
| Wheelbase | 9.19 ft in (2800 mm) |
| Ground Clearance | 1.3 in (33 mm) |
| Turning Radius | 21.66 ft in (6600 mm) |
Platform
| Max Platform Height | 80.06 ft in (24400 mm) |
| Max Horizontal Reach | 71.53 ft in (21800 mm) |
| Platform Rotation | 160 degrees |
| Platform Inner Length | 96.07 in (2440 mm) |
| Max Platform Weight Capacity | 500.45 lb (227 kg) |
| Max Working Height | 85.96 ft in (26200 mm) |
| Platform Inner Width | 35.83 in (910 mm) |
Engine
| Engine Make | 2349 |
| Engine Model | TD2011 L04i |
| Gross Power | 74 hp (55.2 kw) |
| Fuel Type | diesel |
Operational
| Operating Weight | 35501.1 lb (16103 kg) |
| Fuel Capacity | 34.9 gal (132 L) |
| Hydraulic System Fluid Capacity | 39.7 gal (150 L) |
| Max Speed | 3.5 mph (5.6 km/h) |
| Tire Size | 18-625 16PLY |
| Tire Fill/Type | Foam |
