Caterpillar PM565B
Browse All Caterpillar or Cold Planer Models
Contents:
Conveyor System
| Discharge Conveyor Width | 30 in (762 mm) |
Dimensions
| Operating Length | 47.58 ft in (14500 mm) |
| Shipping Width | 10.34 ft in (3151 mm) |
| Max Operating Height | 15.87 ft in (4835 mm) |
Engine
| Number Of Cylinders | 8 |
| Engine Make | 2236 |
| Engine Model | 3408ETA |
| Gross Power | 625 hp (466.1 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 1098.5 cu in (18 L) |
Operational
| Operating Weight - Full Load | 83775.7 lb (38000 kg) |
| Fuel Capacity | 250 gal (946 L) |
| Water Spray System Fluid Capacity | 1001.3 gal (3790 L) |
| Operating Speed | 131.3 ft/min (40 m/min) |
| Travel Speed | 3.8 mph (6 km/h) |
Rotary Cutter
| Cutting Width | 6.9 ft in (2100 mm) |
| Cutting Depth | 12.1 in (305 mm) |
| Number Of Tools | 117 |
Tracks
| Number Of Track Units | 2 |
| Front Track Length | 6.8 ft in (2045 mm) |
| Front Track Width | 13.8 in (348 mm) |
| Rear Track Length | 6.8 ft in (2045 mm) |
| Rear Track Width | 13.8 in (348 mm) |
