John Deere 9870
Browse All John Deere or Combine Models
Contents:
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Power | 440 hp (328.2 kw) |
| Power Boost Power | 471 hp (351.3 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 823.9 cu in (13.5 L) |
Operational
| Operating Weight W/O Attachment | 36114 lb (16381 kg) |
| Fuel Capacity | 305.2 gal (1155 L) |
Feeding
| Conveyor Width | 55 in (1397 mm) |
| Conveyor Length | 68 in (1727 mm) |
Threshing
| Rotor Diameter | 29.6 in (750 mm) |
| Rotor Length | 123.3 in (3130 mm) |
| Rotor Speed - Low | 210 rpm |
| Rotor Speed - High | 1000 rpm |
| Concave Area | 1705.1 in2 (1.1 m2) |
Separating
| Separator Type | rotary |
| Separating Area | 2387.1 in2 (1.6 m2) |
| Discharge Grate Area | 1705.1 in2 (1.1 m2) |
Cleaning System
| Total Cleaning Area | 8137.6 in2 (5.3 m2) |
| Cleaning Fan Speed - Low | 620 rpm |
| Cleaning Fan Speed - High | 1250 rpm |
Grain Handling
| Grain Tank Capacity | 300.9 bu (10600 L) |
| Unloading Auger Length | 22.5 ft in (6.9 m) |
| Unloading Speed | 3.3 bu/sec (116.3 L/sec) |
| Unloading Discharge Height | 14.4 ft in (4.4 m) |
