Liebherr LR1600/2
Browse All Liebherr or Crawler Crane Models
Contents:
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2245 |
| Engine Model | D846 A7 |
| Gross Power | 536.5 hp (400 kw) |
| Net Power | 496.2 hp (370 kw) |
| Power Measured @ | 1900 rpm |
| Max Torque | 1737 lb ft (2355 Nm) |
| Torque Measured @ | 1200 rpm |
Operational
| Fuel Capacity | 369.9 gal (1400 L) |
Boom
| Max Lift Capacity | 1200000 lb (544310.9 kg) |
| Min Working Radius | 78.8 ft in (24 m) |
| Max Working Radius | 472.5 ft in (144 m) |
Dimensions
| Tail Swing Radius | 36.1 ft in (11000 mm) |
