Komatsu D155S-1
Browse All Komatsu or Crawler Loader Models
Contents:
Dimensions
| Length With Bucket On Ground | 25.37 ft in (7730 mm) |
| Width To Outside Of Tracks | 9.91 ft in (3020 mm) |
| Height To Top Of Cab | 12.72 ft in (3875 mm) |
| Clearance At Full Height And Dump | 12.13 ft in (3695 mm) |
| Reach At Dump Height | 5.11 ft in (1555 mm) |
Undercarriage
| Track Gauge | 93.71 in (2380 mm) |
| Length Of Track On Ground | 11.88 ft in (3620 mm) |
Engine
| Engine Make | 2238 |
| Engine Model | S6D155-4 |
| Net Power | 350 hp (261 kw) |
| Aspiration | turbocharged |
| Displacement | 1175 cu in (19.3 L) |
Operational
| Operating Weight | 92150 lb (41798.6 kg) |
| Fuel Capacity | 171.8 gal (650 L) |
| Cooling System Fluid Capacity | 42.3 gal (160 L) |
| Static Tipping Load | 62170 lb (28199.9 kg) |
| Breakout Force - Std Bucket | 59920 lb (266.6 kN) |
| Bucket Capacity - Heaped | 5.9 yd3 (4.5 m3) |
| Max Speed | 6.5 mph (10.3 km/h) |
Hydraulic
| Raise Time | 8 sec |
| Lower Time | 3.1 sec |
