Liebherr LR614
Browse All Liebherr or Crawler Loader Models
Contents:
Dimensions
| Length With Bucket On Ground | 18.71 ft in (5702 mm) |
| Ground Clearance | 1.34 ft in (408 mm) |
| Width To Outside Of Tracks | 6.75 ft in (2057 mm) |
| Height To Top Of Cab | 9.84 ft in (2998 mm) |
| Clearance At Full Height And Dump | 8.57 ft in (2610 mm) |
| Reach At Dump Height | 3.03 ft in (923 mm) |
| Length To Front Of Track | 12.67 ft in (3859 mm) |
Undercarriage
| Track Gauge | 63 in (1600 mm) |
| Length Of Track On Ground | 7.14 ft in (2174 mm) |
| Number Of Shoes Per Side | 38 |
| Number Of Track Rollers Per Side | 6 |
| Ground Pressure | 7.96 psi (54.89 kPa) |
| Track Shoe Width | 18 in (457 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Engine Model | 4045HF289 |
| Net Power | 97 hp (72.4 kw) |
| Power Measured @ | 2200 rpm |
| Aspiration | Turbocharged |
| Displacement | 274.7 cu in (4.5 L) |
Operational
| Operating Weight | 24647.7 lb (11180 kg) |
| Fuel Capacity | 55.5 gal (210 L) |
| Cooling System Fluid Capacity | 6.4 gal (24 L) |
| Engine Oil Capacity | 3.2 gal (12 L) |
| Final Drive Fluid Capacity - Each | 2.4 gal (8.8 L) |
| Hydraulic System Fluid Capacity | 43.1 gal (163 L) |
| Static Tipping Load | 16175.4 lb (7337 kg) |
| Bucket Capacity - Struck | 1.8 yd3 (1.3 m3) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
| Max Speed | 5.9 mph (9.5 km/h) |
Hydraulic
| Pump Type | gear |
| Pump Flow Capacity | 30.4 gal/min (115 L/min) |
| Relief Valve Pressure | 3335 psi (22994 kPa) |
| Raise Time | 6.4 sec |
| Dump Time | 1.9 sec |
| Lower Time | 3.1 sec |
