Caterpillar D3C LGP-S Series II
Browse All Caterpillar or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 13.72 ft in (4180 mm) |
| Width Over Tracks | 9.85 ft in (3000 mm) |
| Height To Top Of Cab | 8.99 ft in (2740 mm) |
| Length Of Track On Ground | 8.04 ft in (2450 mm) |
| Ground Clearance | 0.92 ft in (280 mm) |
| Length W/O Blade | 11.16 ft in (3400 mm) |
Undercarriage
| Track Gauge | 6.57 ft in (2000 mm) |
| Standard Shoe Size | 38.98 in (990 mm) |
| Ground Contact Area | 7517.52 in2 (4.85 m2) |
| Number Of Track Rollers Per Side | 7 |
| Ground Pressure | 2.47 psi (17 kPa) |
Engine
| Engine Make | 2236 |
| Engine Model | 3204 |
| Gross Power | 70 hp (52.2 kw) |
| Displacement | 317.4 cu in (5.2 L) |
Operational
| Operating Weight | 18942.2 lb (8592 kg) |
| Fuel Capacity | 30.2 gal (114 L) |
Transmission
| Transmission Type | powershift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 6.8 mph (10.8 km/h) |
| Max Speed - Reverse | 7.1 mph (11.4 km/h) |
Standard Blade
| Width | 9.2 ft in (2800 mm) |
| Height | 29.1 in (739 mm) |
| Capacity | 1.6 yd3 (1.2 m3) |
| Cutting Depth | 13.9 in (351 mm) |
