Caterpillar D5N XL
Browse All Caterpillar or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 14.97 ft in (4560 mm) |
| Width Over Tracks | 7.65 ft in (2330 mm) |
| Height To Top Of Cab | 9.85 ft in (3000 mm) |
| Length Of Track On Ground | 7.84 ft in (2388 mm) |
| Ground Clearance | 1.25 ft in (378 mm) |
| Length W/O Blade | 11.62 ft in (3540 mm) |
Undercarriage
| Track Gauge | 5.81 ft in (1770 mm) |
| Standard Shoe Size | 22.05 in (560 mm) |
| Ground Contact Area | 4144 in2 (2.68 m2) |
| Number Of Track Rollers Per Side | 7 |
| Ground Pressure | 6.51 psi (44.89 kPa) |
Engine
| Number of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | 3126BT |
| Net Power | 121 hp (90.3 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 439 cu in (7.2 L) |
Operational
| Operating Weight | 28258 lb (12817.7 kg) |
| Fuel Capacity | 67.9 gal (257.1 L) |
Transmission
| Transmission Type | Power shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
| Max Speed - Forward | 5.6 mph (9.1 km/h) |
| Max Speed - Reverse | 6.9 mph (11.2 km/h) |
Undercarriage
| Ground Pressure | 6.6 psi (44.9 kPa) |
| Ground Contact Area | 4144 in2 (2.7 m2) |
| Standard Shoe Size | 22.1 in (560 mm) |
| Number of Track Rollers per Side | 7 |
| Track Gauge | 5.9 ft in (1770 mm) |
Standard Blade
| Width | 10.2 ft in (3080 mm) |
| Height | 43.7 in (1109 mm) |
| Capacity | 3.4 yd3 (2.6 m3) |
| Cutting Depth | 17 in (430 mm) |
Dimensions
| Length w/o Blade | 11.7 ft in (3540 mm) |
| Length w/ Blade | 15 ft in (4560 mm) |
| Width Over Tracks | 7.7 ft in (2330 mm) |
| Height to Top of Cab | 9.9 ft in (3000 mm) |
| Length of Track on Ground | 7.9 ft in (2388 mm) |
| Ground Clearance | 1.3 ft in (378 mm) |
