Caterpillar D7H LGP Series II
Browse All Caterpillar or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 18.18 ft in (5540 mm) |
| Width Over Tracks | 10.34 ft in (3150 mm) |
| Height To Top Of Cab | 11.49 ft in (3500 mm) |
| Length Of Track On Ground | 10.41 ft in (3170 mm) |
| Ground Clearance | 1.61 ft in (490 mm) |
| Length W/O Blade | 15.16 ft in (4620 mm) |
Undercarriage
| Track Gauge | 7.32 ft in (2230 mm) |
| Standard Shoe Size | 36.03 in (915 mm) |
| Ground Contact Area | 9036.52 in2 (5.83 m2) |
| Number Of Track Rollers Per Side | 7 |
| Ground Pressure | 6.31 psi (43.5 kPa) |
Engine
| Engine Make | 2236 |
| Engine Model | 3306 |
| Gross Power | 215 hp (160.4 kw) |
| Displacement | 640.8 cu in (10.5 L) |
Operational
| Operating Weight | 57068.9 lb (25886 kg) |
| Fuel Capacity | 129 gal (488 L) |
Transmission
| Transmission Type | powershift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 7.4 mph (11.9 km/h) |
| Max Speed - Reverse | 8.9 mph (14.3 km/h) |
Standard Blade
| Width | 14.8 ft in (4500 mm) |
| Height | 52.8 in (1341 mm) |
| Capacity | 7.8 yd3 (5.9 m3) |
| Cutting Depth | 26.3 in (668 mm) |
