Caterpillar 552
Browse All Caterpillar or Feller Buncher Models
Contents:
Boom
| Bare Pin Lift At Max Reach | 20723.46 lb (9400 kg) |
Dimensions
| Overall Length | 30.92 ft in (9423 mm) |
| Overall Width | 10.92 ft in (3327 mm) |
| Height To Top Of Cab | 13 ft in (3962 mm) |
| Ground Clearance | 2.92 in (889 mm) |
| Max Reach | 28.22 ft in (8600 mm) |
Undercarriage
| Track Gauge | 8.51 ft in (2591 mm) |
| Shoe Size | 28 in (711 mm) |
| Track Pitch | 8.5 in (215.9 mm) |
| Tractive Effort | 104000.88 lb (47174 kg) |
Engine
| Engine Make | 2236 |
| Engine Model | C9 ACERT |
| Gross Power | 305 hp (227.5 kw) |
| Net Power | 282 hp (210.3 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 537.1 cu in (8.8 L) |
Operational
| Operating Weight W/O Attachment | 78661 lb (35680 kg) |
| Fuel Capacity | 312 gal (1181 L) |
| Cooling System Fluid Capacity | 16.2 gal (61 L) |
| Engine Oil Capacity | 10.4 gal (39 L) |
| Hydraulic System Fluid Capacity | 97.8 gal (370 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 95 amps |
Upperstructure Leveling
| Front | 20 degrees |
| Side | 11 degrees |
