BT DT20N
Contents:
Dimensions
| Length To Fork Face | 7.86 ft in (2395 mm) |
| Overall Width | 3.79 ft in (1155 mm) |
| Overall Height - Mast Lowered | 6.48 ft in (1975 mm) |
| Wheelbase | 4.88 ft in (1485 mm) |
| Ground Clearance | 3.15 in (80 mm) |
| Height To Top Of Overhead Guard | 6.85 ft in (2085 mm) |
| Max Fork Height | 9.85 ft in (3000 mm) |
| Turning Radius | 6.7 ft in (2040 mm) |
Mast
| Mast Tip Forward | 7 degrees |
| Mast Tip Rear | 10 degrees |
| Lower Speed | 98.43 ft/min (30 m/min) |
| Load Capacity | 4409.25 lb (2000 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 118.12 ft/min (36 m/min) |
Engine
| Engine Make | 2304 |
| Engine Model | 1DZ-III |
| Power | 51 hp (38 kw) |
| Torque | 115.8 lb ft (157 Nm) |
| Power Measured @ | 2400 rpm |
| Displacement | 151.8 cu in (2.5 L) |
| Torque Measured @ | 2300 rpm |
| Fuel Type | diesel |
Operational
| Operating Weight | 71033 lb (32220 kg) |
| Tire Type | pneumatic front 21x8-9-14PR rear 18x7-8-10PR |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 10.9 mph (17.5 km/h) |
