Caterpillar GC45K STR
Browse All Caterpillar or Forklift Models
Contents:
Dimensions
| Length To Fork Face | 8.19 ft in (2496 mm) |
| Overall Width | 3.88 ft in (1180 mm) |
| Overall Height - Mast Lowered | 6.96 ft in (2120 mm) |
| Wheelbase | 5.17 ft in (1575 mm) |
| Ground Clearance | 3.94 in (100 mm) |
| Height To Top Of Overhead Guard | 7.24 ft in (2205 mm) |
| Max Fork Height | 9.52 ft in (2900 mm) |
| Turning Radius | 7.33 ft in (2234 mm) |
Mast
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 10 degrees |
| Max Fork Spread | 41 in (1041.41 mm) |
| Lower Speed | 81 ft/min (24.69 m/min) |
| Load Center | 23.63 in (600 mm) |
| Load Capacity | 9920.81 lb (4500 kg) |
| Lift Speed | 83 ft/min (25.3 m/min) |
Engine
| Engine Make | 2374 |
| Engine Model | V6 |
| Power | 92.5 hp (69 kw) |
| Torque | 220 lb ft (298.3 Nm) |
| Power Measured @ | 2450 rpm |
| Displacement | 262402.2 cu in (4300 L) |
| Torque Measured @ | 1200 rpm |
| Fuel Type | gas |
Operational
| Operating Weight | 14350 lb (6509.1 kg) |
| Tire Type | cushion |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 12.1 mph (19.5 km/h) |
