Hyster H110FT
Contents:
Dimensions
| Length To Fork Face | 10.8 ft in (3290 mm) |
| Overall Width | 4.76 ft in (1450 mm) |
| Overall Height - Mast Lowered | 7.27 ft in (2214 mm) |
| Wheelbase | 6.89 ft in (2100 mm) |
| Ground Clearance | 9.34 in (237 mm) |
| Height To Top Of Overhead Guard | 7.56 ft in (2302 mm) |
| Gradeability | 27 % |
| Right Angle Stack | 11.37 ft in (3465 mm) |
| Turning Radius | 9.44 ft in (2877 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Load Center | 24.02 in (610 mm) |
| Lift Speed | 98 ft/min (29.88 m/min) |
| Lower Speed | 100 ft/min (30.48 m/min) |
| Load Capacity | 11000 lb (4989.52 kg) |
| Max Fork Spread | 49.69 in (1262 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Model | PSI 4.3L V6 |
| Power | 88 hp (65.7 kw) |
| Torque | 210 lb ft (284.8 Nm) |
| Power Measured @ | 2200 rpm |
| Displacement | 263 cu in (4.4 L) |
| Torque Measured @ | 2200 rpm |
| Fuel Type | LPG |
Operational
| Operating Weight | 15560 lb (7057.9 kg) |
| Tire Type | Pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 11.7 mph (18.9 km/h) |
| Drawbar Pull | 6881 lb (3121.2 kg) |
| Front Tire Size | 300 x 15 - 20 Ply |
| Hydraulic System Relief Valve Pressure | 2250 psi (15513.2 kPa) |
| Rear Tire Size | 7.00 x 12 - 14 Ply |
| Hydraulic Tank | 17.9 gal (67.8 L) |
| Axle Load - Front | 6499 lb (2947.9 kg) |
| Axle Load - Rear | 9061 lb (4110.1 kg) |
Brakes
| Service Brake | Foot/Hydraulic |
| Parking Brake | Hand/Mechanical |
