Komatsu FS20S-1
Contents:
Dimensions
| Length To Fork Face | 5.88 ft in (1790 mm) |
| Overall Width | 3.47 ft in (1055 mm) |
| Overall Height - Mast Lowered | 6.93 ft in (2110 mm) |
| Wheelbase | 4.27 ft in (1300 mm) |
| Ground Clearance | 3.94 in (100 mm) |
| Height To Top Of Overhead Guard | 7.09 ft in (2160 mm) |
| Max Fork Height | 15.82 ft in (4820 mm) |
| Right Angle Stack | 5.91 ft in (1800 mm) |
| Turning Radius | 4.93 ft in (1500 mm) |
Mast
| Mast Tip Forward | 3 degrees |
| Mast Tip Rear | 5 degrees |
| Number Of Mast Sections | 3 |
| Lower Speed | 90 ft/min (27.44 m/min) |
| Load Center | 23.63 in (600 mm) |
| Load Capacity | 4000 lb (1814.37 kg) |
| Lift Speed | 52 ft/min (15.85 m/min) |
Engine
| Engine Make | 0 |
| Fuel Type | Electric 36V |
Operational
| Operating Weight | 9450 lb (4286.5 kg) |
| Tire Type | Cushion Solid |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 1 |
| Max Speed | 6.2 mph (10 km/h) |
