Komatsu FS25SH-1
Contents:
Dimensions
| Length To Fork Face | 6.37 ft in (1940 mm) |
| Overall Width | 3.5 ft in (1065 mm) |
| Overall Height - Mast Lowered | 6.93 ft in (2110 mm) |
| Wheelbase | 4.65 ft in (1415 mm) |
| Ground Clearance | 3.94 in (100 mm) |
| Height To Top Of Overhead Guard | 6.93 ft in (2110 mm) |
| Max Fork Height | 15.49 ft in (4720 mm) |
| Right Angle Stack | 6.4 ft in (1950 mm) |
| Turning Radius | 5.32 ft in (1620 mm) |
Mast
| Mast Tip Forward | 3 degrees |
| Mast Tip Rear | 5 degrees |
| Number Of Mast Sections | 3 |
| Lower Speed | 90 ft/min (27.44 m/min) |
| Load Center | 23.63 in (600 mm) |
| Load Capacity | 5000 lb (2267.97 kg) |
| Lift Speed | 55 ft/min (16.77 m/min) |
Engine
| Engine Make | 0 |
| Fuel Type | Electric 36V |
Operational
| Operating Weight | 10365 lb (4701.5 kg) |
| Tire Type | Cushion Solid |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 7 mph (11.3 km/h) |
