Manitou MC 30
Contents:
Dimensions
| Length To Fork Face | 11.3 ft in (3442 mm) |
| Overall Width | 6.24 ft in (1900 mm) |
| Overall Height - Mast Lowered | 7.24 ft in (2205 mm) |
| Wheelbase | 6.55 ft in (1995 mm) |
| Ground Clearance | 15.16 in (385 mm) |
| Height To Top Of Overhead Guard | 8.08 ft in (2460 mm) |
| Turning Radius | 10.54 ft in (3210 mm) |
Mast
| Max Fork Spread | 57.88 in (1470 mm) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 112.21 ft/min (34.21 m/min) |
| Load Capacity | 6613.87 lb (3000 kg) |
| Lower Speed | 94.49 ft/min (28.8 m/min) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1104C 44 |
| Power | 82.5 hp (61.5 kw) |
| Torque | 222.8 lb ft (302 Nm) |
| Power Measured @ | 2200 rpm |
| Displacement | 268.6 cu in (4.4 L) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 11221.6 lb (5090 kg) |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 15 mph (24 km/h) |
