TCM FD370Z5
Contents:
| Length To Fork Face | 31.63 ft in (9640 mm) |
| Overall Width | 13.26 ft in (4040 mm) |
| Wheelbase | 15.75 ft in (4800 mm) |
| Ground Clearance | 13 in (330 mm) |
| Max Fork Height | 31.35 ft in (9555 mm) |
| Turning Radius | 22.64 ft in (6900 mm) |
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Load Center | 49.22 in (1250 mm) |
| Load Capacity | 81571.04 lb (37000 kg) |
| Lift Speed | 43.3 ft/min (13.2 m/min) |
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | 6RBI-T |
| Power | 300 hp (223.8 kw) |
| Torque | 846.3 lb ft (1147.4 Nm) |
| Power Measured @ | 2000 rpm |
| Displacement | 838.6 cu in (13.8 L) |
| Torque Measured @ | 1400 rpm |
| Fuel Type | diesel |
| Operating Weight | 130072.8 lb (59000 kg) |
| Tire Type | 18.00-25-36 |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 17.4 mph (28.1 km/h) |
