Yale 35D-7
Contents:
Dimensions
| Length To Fork Face | 10.08 ft in (3070 mm) |
| Overall Width | 4.6 ft in (1400 mm) |
| Overall Height - Mast Lowered | 7.34 ft in (2235 mm) |
| Wheelbase | 6.57 ft in (2000 mm) |
| Ground Clearance | 8.47 in (215 mm) |
| Height To Top Of Overhead Guard | 7.35 ft in (2240 mm) |
| Max Fork Height | 13.9 ft in (4236 mm) |
| Turning Radius | 9.09 ft in (2770 mm) |
Mast
| Mast Tip Forward | 8 degrees |
| Mast Tip Rear | 10 degrees |
| Lower Speed | 1476.39 ft/min (450 m/min) |
| Load Capacity | 77161.79 lb (35000 kg) |
| Load Center | 23.63 in (600 mm) |
| Lift Speed | 1968.52 ft/min (600 m/min) |
Engine
| Engine Make | 2247 |
| Engine Model | HMC/D4D4 |
| Power | 91.2 hp (68 kw) |
Operational
| Operating Weight | 12980.9 lb (5888 kg) |
| Tire Type | Pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 18.1 mph (29.1 km/h) |
