Caterpillar 574
Browse All Caterpillar or Forwarder Models
Contents:
Dimensions
| Length | 30.71 ft in (9360 mm) |
| Width Over Tires | 9.29 ft in (2830 mm) |
| Height To Top Of Crane | 12.11 ft in (3690 mm) |
| Ground Clearance | 2.14 ft in (650 mm) |
| Length Of Bunk Area | 17.72 ft in (5400 mm) |
| Width Of Bunk Area | 9.29 ft in (2830 mm) |
Engine
| Engine Make | 2236 |
| Engine Model | 3126 DITA |
| Power | 154.3 hp (115 kw) |
| Gross Power | 173 hp (129.1 kw) |
| Torque | 555 lb ft (752.5 Nm) |
| Power Measured @ | 2200 rpm |
| Displacement | 439 cu in (7.2 L) |
| Torque Measured @ | 1600 rpm |
| Engine Model | Cat C6.6 ACERT |
Operational
| Operating Weight - 8wd | 37000 lb (16783 kg) |
| Fuel Capacity | 33.1 gal (125 L) |
| Front/Rear Tire Size - 8wd | 700/50-26.5 16PR |
Transmission
| Transmission Type | Hydrostatic/Mechanical |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed | 15.5 mph (25 km/h) |
| Transmission | Electric Power Shift |
| Gears | 4/4 |
Weights
| Operating Weight | 38000 lb (17236.6 kg) |
| Gross (Loaded) Machine Weight | 35274 lb (16000 kg) |
Tires
| Tire Size - Front - Optional | 800/50 x 26.5 |
| Tire Size - Rear - Optional | 800/50 x 26.5 |
Bunk
| Load Weight - 8wd | 30800 lb (13970.7 kg) |
Hydraulic System
| Flow Rate | 66 gal/min |
| Hydraulic Fluid Reservoir | 32 gal (121.2 L) |
Crane
| Crane Type | F71 F73 |
| Max Reach | 23.5 ft in (7162.8 mm) |
| Gross Lift Torque | 16875 lb ft (22879.5 Nm) |
Operating Specifications
| Payload | 32000 lb (14515 kg) |
| Wood Bunk Length | 222 in (5638.8 mm) |
| Maximum Speed - 6wd | 14.5 mph (23.4 km/h) |
| Load Capacity | 32000 lb (14515 kg) |
| Load Capacity - With Clam Bunk Attachment | 26000 lb (11793.5 kg) |
| Loader Reach | 22.9 ft in (7 m) |
| Maximum Travel Speed | 8.1 mph (13.1 km/h) |
Service Refill Capacities
| Fuel Tank | 47 gal (178 L) |
