Link-Belt 290LX
Browse All Link-Belt or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 34.16 ft in (10410 mm) |
| Shipping Height Of Unit | 10.73 ft in (3270 mm) |
| Max Cutting Height | 33.14 ft in (10100 mm) |
| Max Loading Height | 23.27 ft in (7090 mm) |
| Max Reach Along Ground | 34.59 ft in (10540 mm) |
| Max Vertical Wall Digging Depth | 19.82 ft in (6040 mm) |
| Max Digging Depth | 23.4 ft in (7130 mm) |
| Boom/Stick Option (Hex) 1 | Boom 20'2" (6150mm) / Stick 10'6" (3200mm) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 34.16 ft in (10410 mm) |
| Max Cutting Height | 32.85 ft in (10010 mm) |
| Shipping Height Of Unit | 10.73 ft in (3270 mm) |
| Max Loading Height | 22.87 ft in (6970 mm) |
| Max Reach Along Ground | 33.14 ft in (10100 mm) |
| Max Vertical Wall Digging Depth | 18.57 ft in (5660 mm) |
| Max Digging Depth | 21.66 ft in (6600 mm) |
| Boom/Stick Option (Hex) 2 | Boom 20'2" (6150mm) / Stick 8'9" (2670mm) |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 34.22 ft in (10430 mm) |
| Max Cutting Height | 34.09 ft in (10390 mm) |
| Max Loading Height | 24.15 ft in (7360 mm) |
| Shipping Height Of Unit | 11.42 ft in (3480 mm) |
| Max Reach Along Ground | 36.09 ft in (11000 mm) |
| Max Vertical Wall Digging Depth | 21.82 ft in (6650 mm) |
| Max Digging Depth | 24.91 ft in (7590 mm) |
| Boom/Stick Option (Hex) 3 | Boom 20'2" (6150mm) / Stick 12'0" (3660mm) |
Dimensions
| Ground Clearance | 1.61 ft in (490 mm) |
| Height To Top Of Cab | 10.01 ft in (3050 mm) |
| Width To Outside Of Tracks | 11.16 ft in (3400 mm) |
| Length Of Track On Ground | 12.9 ft in (3930 mm) |
| Tail Swing Radius | 10.44 ft in (3180 mm) |
| Removal Counterweight Clearance | 3.94 ft in (1200 mm) |
Undercarriage
| Track Gauge | 8.54 ft in (2600 mm) |
| Shoe Size | 31.5 in (800 mm) |
| Number Of Track Rollers Per Side | 8 |
| Number Of Carrier Rollers Per Side | 2 |
| Max Travel Speed | 3.2 mph (5.15 km/h) |
| Ground Pressure | 6.09 psi (41.99 kPa) |
| Number Of Shoes Per Side | 47 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | CC-6BG1TC |
| Net Power | 177 hp (132 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 443 lb ft (600.7 Nm) |
| Displacement | 396 cu in (6.5 L) |
| Aspiration | Turbocharged with Intercooler |
| Torque Measured @ | 1800 rpm |
Operational
| Operating Weight | 64400 lb (29211.4 kg) |
| Fuel Capacity | 89.9 gal (340 L) |
| Cooling System Fluid Capacity | 7.7 gal (29 L) |
| Hydraulic System Fluid Capacity | 63.5 gal (240 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 6.4 gal (24 L) |
| Swing Drive Fluid Capacity | 1.6 gal (6 L) |
| Alternator Supplied Amperage | 50 amps |
| Hydraulic System Relief Valve Pressure | 4970 psi (34267 kPa) |
| Hydraulic Pump Flow Capacity | 116.8 gal/min (442.2 L/min) |
Swing Mechanism
| Swing Speed | 10.4 rpm |
| Swing Torque | 55130 lb ft (74746.3 Nm) |
Buckets
| Reference Bucket Capacity | 1.3 yd3 (1 m3) |
| Minimum Bucket Capacity | 0.8 yd3 (0.7 m3) |
| Maximum Bucket Capacity | 2.5 yd3 (1.9 m3) |
