Link-Belt 3400 Quantum Long Front
Browse All Link-Belt or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 47.58 ft in (14500 mm) |
| Shipping Height Of Unit | 10.21 ft in (3110 mm) |
| Max Cutting Height | 45.15 ft in (13760 mm) |
| Max Loading Height | 38.06 ft in (11600 mm) |
| Max Reach Along Ground | 59.95 ft in (18270 mm) |
| Max Vertical Wall Digging Depth | 39.87 ft in (12150 mm) |
| Max Digging Depth | 47.58 ft in (14500 mm) |
| Boom/Stick Option (Hex) 1 | Boom 33'10" (10300mm) / Stick 25'11" (7900mm) |
Dimensions
| Ground Clearance | 1.51 ft in (460 mm) |
| Height To Top Of Cab | 9.81 ft in (2990 mm) |
| Width To Outside Of Tracks | 11.13 ft in (3390 mm) |
| Length Of Track On Ground | 12.6 ft in (3840 mm) |
| Tail Swing Radius | 9.81 ft in (2990 mm) |
| Removal Counterweight Clearance | 3.61 ft in (1100 mm) |
Undercarriage
| Track Gauge | 8.5 ft in (2590 mm) |
| Shoe Size | 31.5 in (800 mm) |
| Number Of Shoes Per Side | 51 |
| Max Travel Speed | 3.4 mph (5.48 km/h) |
| Number Of Track Rollers Per Side | 9 |
| Ground Pressure | 5.83 psi (40.2 kPa) |
| Number Of Carrier Rollers Per Side | 2 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | 6BG1T |
| Net Power | 153 hp (114.1 kw) |
| Power Measured @ | 2150 rpm |
| Max Torque | 388 lb ft (526.1 Nm) |
| Displacement | 396 cu in (6.5 L) |
| Aspiration | Turbocharged |
| Torque Measured @ | 1700 rpm |
Operational
| Operating Weight | 61300 lb (27805.3 kg) |
| Fuel Capacity | 81.9 gal (310 L) |
| Cooling System Fluid Capacity | 7.1 gal (26.7 L) |
| Hydraulic System Fluid Capacity | 58.2 gal (220 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 5.2 gal (19.5 L) |
| Swing Drive Fluid Capacity | 1.6 gal (6 L) |
| Alternator Supplied Amperage | 40 amps |
| Hydraulic System Relief Valve Pressure | 4980 psi (34335.9 kPa) |
| Hydraulic Pump Flow Capacity | 110 gal/min (416.4 L/min) |
Swing Mechanism
| Swing Speed | 9.7 rpm |
| Swing Torque | 47380 lb ft (64238.7 Nm) |
Buckets
| Reference Bucket Capacity | 0.8 yd3 (0.6 m3) |
| Minimum Bucket Capacity | 0.8 yd3 (0.6 m3) |
| Maximum Bucket Capacity | 0.9 yd3 (0.7 m3) |
