New Holland 115SR
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 22.61 ft in (6890 mm) |
| Shipping Height Of Unit | 9.22 ft in (2810 mm) |
| Max Cutting Height | 26.12 ft in (7960 mm) |
| Max Loading Height | 18.28 ft in (5570 mm) |
| Max Reach Along Ground | 23.92 ft in (7290 mm) |
| Max Vertical Wall Digging Depth | 13 ft in (3960 mm) |
| Max Digging Depth | 15.62 ft in (4760 mm) |
| Boom/Stick Option (Hex) 1 | stick 1900mm |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 22.61 ft in (6890 mm) |
| Max Cutting Height | 26.78 ft in (8160 mm) |
| Shipping Height Of Unit | 9.22 ft in (2810 mm) |
| Max Loading Height | 18.97 ft in (5780 mm) |
| Max Reach Along Ground | 24.91 ft in (7590 mm) |
| Max Vertical Wall Digging Depth | 14.77 ft in (4500 mm) |
| Max Digging Depth | 16.61 ft in (5060 mm) |
| Boom/Stick Option (Hex) 2 | stick 2200mm |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 22.61 ft in (6890 mm) |
| Max Cutting Height | 27.86 ft in (8490 mm) |
| Max Loading Height | 20.02 ft in (6100 mm) |
| Shipping Height Of Unit | 9.22 ft in (2810 mm) |
| Max Reach Along Ground | 26.42 ft in (8050 mm) |
| Max Vertical Wall Digging Depth | 15.95 ft in (4860 mm) |
| Max Digging Depth | 18.25 ft in (5560 mm) |
| Boom/Stick Option (Hex) 3 | stick 2700mm |
Dimensions
| Ground Clearance | 1.5 ft in (455 mm) |
| Height To Top Of Cab | 8.99 ft in (2740 mm) |
| Width To Outside Of Tracks | 8.17 ft in (2490 mm) |
| Length Of Track On Ground | 8.57 ft in (2610 mm) |
| Tail Swing Radius | 4.55 ft in (1385 mm) |
| Removal Counterweight Clearance | 2.99 ft in (910 mm) |
Undercarriage
| Track Gauge | 6.53 ft in (1990 mm) |
| Shoe Size | 19.69 in (500 mm) |
| Number Of Track Rollers Per Side | 6 |
| Ground Pressure | 5.81 psi (40 kPa) |
| Max Travel Speed | 3.73 mph (6 km/h) |
| Number Of Carrier Rollers Per Side | 1 |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2353 |
| Engine Model | - 4BG1TA |
| Net Power | 81 hp (60.5 kw) |
| Power Measured @ | 2050 rpm |
| Displacement | 264.2 cu in (4.4 L) |
| Aspiration | Turbo |
Operational
| Operating Weight | 28219.2 lb (12800 kg) |
| Fuel Capacity | 44.4 gal (168 L) |
| Cooling System Fluid Capacity | 4.8 gal (18 L) |
| Hydraulic System Fluid Capacity | 37 gal (140 L) |
| Engine Oil Capacity | 3.5 gal (13 L) |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.5 gal (1.7 L) |
| Alternator Supplied Amperage | 30 amps |
| Hydraulic System Relief Valve Pressure | 5076.4 psi (35000 kPa) |
| Hydraulic Pump Flow Capacity | 62.4 gal/min (236 L/min) |
Swing Mechanism
| Swing Speed | 11.4 rpm |
Buckets
| Reference Bucket Capacity | 0.6 yd3 (0.5 m3) |
| Minimum Bucket Capacity | 0.6 yd3 (0.5 m3) |
| Maximum Bucket Capacity | 0.8 yd3 (0.6 m3) |
