Sumitomo SH330LC-5
Browse All Sumitomo or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 36.26 ft in (11050 mm) |
| Shipping Height Of Unit | 10.7 ft in (3260 mm) |
| Max Loading Height | 23.73 ft in (7230 mm) |
| Max Reach Along Ground | 36.39 ft in (11090 mm) |
| Max Vertical Wall Digging Depth | 20.84 ft in (6350 mm) |
| Max Digging Depth | 24.12 ft in (7350 mm) |
Dimensions
| Ground Clearance | 1.58 ft in (480 mm) |
| Width To Outside Of Tracks | 10.5 ft in (3200 mm) |
| Length Of Track On Ground | 13.26 ft in (4040 mm) |
| Tail Swing Radius | 11.32 ft in (3450 mm) |
Undercarriage
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | AA-6HK1XYSS |
| Gross Power | 270.9 hp (202 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 475.4 cu in (7.8 L) |
Operational
| Operating Weight | 74957.2 lb (34000 kg) |
| Hydraulic System Relief Valve Pressure | 4974.8 psi (34300 kPa) |
| Hydraulic Pump Flow Capacity | 153.3 gal/min (580 L/min) |
Buckets
| Reference Bucket Capacity | 1.9 yd3 (1.4 m3) |
