Sunward SWE330LC
Browse All Sunward or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 36.57 ft in (11145 mm) |
| Shipping Height Of Unit | 11.09 ft in (3380 mm) |
| Max Cutting Height | 34.85 ft in (10620 mm) |
| Max Loading Height | 24.87 ft in (7580 mm) |
| Max Reach Along Ground | 36.42 ft in (11100 mm) |
| Max Vertical Wall Digging Depth | 21.63 ft in (6590 mm) |
| Max Digging Depth | 24.45 ft in (7450 mm) |
| Boom/Stick Option (Hex) 1 | Boom 6500mm/Stick 3260mm |
Dimensions
| Ground Clearance | 1.68 ft in (510 mm) |
| Height To Top Of Cab | 10.27 ft in (3130 mm) |
| Width To Outside Of Tracks | 10.47 ft in (3190 mm) |
| Tail Swing Radius | 11.13 ft in (3390 mm) |
| Removal Counterweight Clearance | 3.93 ft in (1195 mm) |
Undercarriage
| Track Gauge | 8.5 ft in (2590 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 2.93 mph (4.7 km/h) |
Engine
| Engine Make | 2353 |
| Engine Model | AA-6HK1XQP |
| Net Power | 246.7 hp (183.9 kw) |
| Max Torque | 643.8 lb ft (872.8 Nm) |
| Aspiration | turbocharged |
| Displacement | 475.4 cu in (7.8 L) |
Operational
| Operating Weight | 73193.5 lb (33200 kg) |
| Fuel Capacity | 159.9 gal (605 L) |
| Hydraulic System Fluid Capacity | 76.7 gal (290 L) |
| Hydraulic System Relief Valve Pressure | 4699.3 psi (32400 kPa) |
| Hydraulic Pump Flow Capacity | 141.6 gal/min (536 L/min) |
Swing Mechanism
| Swing Speed | 10.3 rpm |
