Terex TXC420LC-1
Browse All Terex or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 38.36 ft in (11690 mm) |
| Shipping Height Of Unit | 11.73 ft in (3575 mm) |
| Max Cutting Height | 36.09 ft in (11000 mm) |
| Max Loading Height | 25.74 ft in (7845 mm) |
| Max Reach Along Ground | 37.11 ft in (11310 mm) |
| Max Vertical Wall Digging Depth | 14.44 ft in (4400 mm) |
| Max Digging Depth | 25.35 ft in (7725 mm) |
| Boom/Stick Option (Hex) 1 | 22'4'' (6700mm) boom w/ stick 10'8'' (3250mm) |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 37.72 ft in (11495 mm) |
| Max Loading Height | 27.33 ft in (8330 mm) |
| Max Reach Along Ground | 39.6 ft in (12070 mm) |
| Max Vertical Wall Digging Depth | 16.62 ft in (5065 mm) |
| Max Digging Depth | 27.79 ft in (8470 mm) |
| Boom/Stick Option (Hex) 2 | 22'4'' (6700mm) boom w/ stick 13'1'' (4000mm) |
Dimensions
| Ground Clearance | 1.78 ft in (540 mm) |
| Height To Top Of Cab | 10.34 ft in (3150 mm) |
| Width To Outside Of Tracks | 11 ft in (3350 mm) |
| Length Of Track On Ground | 13.95 ft in (4250 mm) |
| Tail Swing Radius | 12.01 ft in (3660 mm) |
| Removal Counterweight Clearance | 4.19 ft in (1277 mm) |
Undercarriage
| Track Gauge | 9.03 ft in (2750 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
| Number Of Shoes Per Side | 50 |
| Number Of Track Rollers Per Side | 9 |
| Ground Pressure | 10.4 psi (71.71 kPa) |
| Number Of Carrier Rollers Per Side | 2 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2253 |
| Engine Model | DE12TIS |
| Net Power | 281 hp (209.6 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 853 lb ft (1156.6 Nm) |
| Displacement | 675 cu in (11.1 L) |
| Aspiration | Turbocharged air to air intercooled |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 90830 lb (41199.8 kg) |
| Fuel Capacity | 145.3 gal (550 L) |
| Cooling System Fluid Capacity | 14.8 gal (56 L) |
| Hydraulic System Fluid Capacity | 108.4 gal (410 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 7.4 gal (28 L) |
| Swing Drive Fluid Capacity | 1.6 gal (6 L) |
| Hydraulic System Relief Valve Pressure | 4550 psi (31371.2 kPa) |
| Hydraulic Pump Flow Capacity | 166.5 gal/min (630 L/min) |
Swing Mechanism
| Swing Speed | 9.5 rpm |
Buckets
| Reference Bucket Capacity | 2.5 yd3 (2 m3) |
| Minimum Bucket Capacity | 1.9 yd3 (1.5 m3) |
| Maximum Bucket Capacity | 2.9 yd3 (2.2 m3) |
