Hyundai R800LC-7A
Browse All Hyundai or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 42.98 ft in (13100 mm) |
| Shipping Height Of Unit | 16.54 ft in (5040 mm) |
| Max Cutting Height | 38.55 ft in (11750 mm) |
| Max Loading Height | 24.61 ft in (7500 mm) |
| Max Reach Along Ground | 39.28 ft in (11970 mm) |
| Max Vertical Wall Digging Depth | 18.61 ft in (5670 mm) |
| Max Digging Depth | 23.76 ft in (7240 mm) |
| Boom/Stick Option (Hex) 1 | Boom 23'7" (7200mm) / Stick 9'8" (2950mm) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 45.77 ft in (13950 mm) |
| Max Cutting Height | 38.78 ft in (11820 mm) |
| Shipping Height Of Unit | 17.59 ft in (5360 mm) |
| Max Loading Height | 25.4 ft in (7740 mm) |
| Max Reach Along Ground | 43.18 ft in (13160 mm) |
| Max Vertical Wall Digging Depth | 20.31 ft in (6190 mm) |
| Max Digging Depth | 27.73 ft in (8450 mm) |
| Boom/Stick Option (Hex) 2 | Boom 26'5" (8050mm) / Stick 11'2" (3400mm) |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 46.3 ft in (14110 mm) |
| Max Cutting Height | 38.65 ft in (11780 mm) |
| Max Loading Height | 25.5 ft in (7770 mm) |
| Shipping Height Of Unit | 17.23 ft in (5250 mm) |
| Max Reach Along Ground | 44.03 ft in (13420 mm) |
| Max Vertical Wall Digging Depth | 20.25 ft in (6170 mm) |
| Max Digging Depth | 28.71 ft in (8750 mm) |
| Boom/Stick Option (Hex) 3 | Boom 26'11" (8200mm) / Stick 11'8" (3600mm) |
Dimensions
| Ground Clearance | 2.89 ft in (880 mm) |
| Height To Top Of Cab | 11.75 ft in (3580 mm) |
| Width To Outside Of Tracks | 14.42 ft in (4395 mm) |
| Length Of Track On Ground | 16.51 ft in (5030 mm) |
| Tail Swing Radius | 14.16 ft in (4315 mm) |
| Removal Counterweight Clearance | 5.16 ft in (1570 mm) |
Undercarriage
| Track Gauge | 11.49 ft in (3500 mm) |
| Shoe Size | 27.56 in (700 mm) |
| Number Of Track Rollers Per Side | 9 |
| Number Of Carrier Rollers Per Side | 3 |
| Max Travel Speed | 2.49 mph (4 km/h) |
| Ground Pressure | 15.22 psi (104.94 kPa) |
| Number Of Shoes Per Side | 51 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | QSX15 |
| Gross Power | 510 hp (380.4 kw) |
| Net Power | 490 hp (365.4 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1744 lb ft (2364.6 Nm) |
| Displacement | 915 cu in (15 L) |
| Aspiration | Turbocharged |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 181484.6 lb (82320 kg) |
| Fuel Capacity | 248.4 gal (940 L) |
| Cooling System Fluid Capacity | 15.6 gal (59 L) |
| Hydraulic System Fluid Capacity | 211.4 gal (800 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 11.5 gal (43.5 L) |
| Swing Drive Fluid Capacity | 1.6 gal (6 L) |
| Alternator Supplied Amperage | 100 amps |
| Hydraulic System Relief Valve Pressure | 4980 psi (34335.9 kPa) |
| Hydraulic Pump Flow Capacity | 266.3 gal/min (1008 L/min) |
Swing Mechanism
| Swing Speed | 6.3 rpm |
Buckets
| Reference Bucket Capacity | 6 yd3 (4.6 m3) |
| Minimum Bucket Capacity | 4.5 yd3 (3.4 m3) |
| Maximum Bucket Capacity | 6.7 yd3 (5.1 m3) |
