John Deere 250G LC
Browse All John Deere or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 33.96 ft in (10350 mm) |
| Shipping Height Of Unit | 10.08 ft in (3070 mm) |
| Max Cutting Height | 33.34 ft in (10160 mm) |
| Max Loading Height | 23.63 ft in (7200 mm) |
| Max Reach Along Ground | 33.17 ft in (10110 mm) |
| Max Vertical Wall Digging Depth | 19.79 ft in (6030 mm) |
| Max Digging Depth | 22.84 ft in (6960 mm) |
| Boom/Stick Option (Hex) 1 | Arm Length 2.96 m (9 ft. 9 in.) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 34.16 ft in (10410 mm) |
| Max Cutting Height | 34.65 ft in (10560 mm) |
| Shipping Height Of Unit | 10.31 ft in (3140 mm) |
| Max Loading Height | 24.87 ft in (7580 mm) |
| Max Reach Along Ground | 35.27 ft in (10750 mm) |
| Max Vertical Wall Digging Depth | 22.12 ft in (6740 mm) |
| Max Digging Depth | 24.97 ft in (7610 mm) |
| Boom/Stick Option (Hex) 2 | Arm Length 3.61 m (11 ft. 10 in.) |
Dimensions
| Ground Clearance | 1.51 ft in (460 mm) |
| Height To Top Of Cab | 9.88 ft in (3010 mm) |
| Width To Outside Of Tracks | 11.13 ft in (3390 mm) |
| Length Of Track On Ground | 12.6 ft in (3840 mm) |
| Tail Swing Radius | 10.31 ft in (3140 mm) |
| Removal Counterweight Clearance | 3.58 ft in (1090 mm) |
Undercarriage
| Shoe Size | 32 in (812.8 mm) |
| Number Of Shoes Per Side | 51 |
| Ground Pressure | 5.37 psi (37 kPa) |
| Max Travel Speed | 3.4 mph (5.48 km/h) |
| Number Of Track Rollers Per Side | 9 |
| Number Of Carrier Rollers Per Side | 2 |
| Drawbar Pull | 49935 lb (222.13 kN) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | PowerTech™ PVX 6.8 L |
| Net Power | 187.8 hp (140 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 415 cu in (6.9 L) |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 55735.1 lb (25281 kg) |
| Fuel Capacity | 132.1 gal (500 L) |
| Cooling System Fluid Capacity | 6.1 gal (23 L) |
| Hydraulic System Fluid Capacity | 63.5 gal (240 L) |
| Engine Oil Capacity | 5.2 gal (19.5 L) |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.9 gal (7 L) |
| Alternator Supplied Amperage | 100 amps |
| Hydraulic System Relief Valve Pressure | 565.7 psi (3900 kPa) |
| Hydraulic Pump Flow Capacity | 9 gal/min (34 L/min) |
Swing Mechanism
| Swing Torque | 54857 lb ft (74376 Nm) |
| Swing Speed | 13.5 rpm |
Buckets
| Reference Bucket Capacity | 1.4 yd3 (1.1 m3) |
| Minimum Bucket Capacity | 1 yd3 (0.7 m3) |
| Maximum Bucket Capacity | 2.1 yd3 (1.6 m3) |
