Komatsu PC300LC-6 EXCEL
Browse All Komatsu or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 36.44 ft in (11105 mm) |
| Shipping Height Of Unit | 11.37 ft in (3465 mm) |
| Max Cutting Height | 31.44 ft in (9580 mm) |
| Max Loading Height | 21.64 ft in (6595 mm) |
| Max Reach Along Ground | 32.65 ft in (9950 mm) |
| Max Vertical Wall Digging Depth | 16.8 ft in (5120 mm) |
| Max Digging Depth | 20.85 ft in (6355 mm) |
| Boom/Stick Option (Hex) 1 | Boom 21'3" (6470mm)/Stick 7'3" (2200mm) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 36.06 ft in (10990 mm) |
| Max Cutting Height | 32.7 ft in (9965 mm) |
| Shipping Height Of Unit | 11.23 ft in (3420 mm) |
| Max Loading Height | 22.63 ft in (6895 mm) |
| Max Reach Along Ground | 33.98 ft in (10355 mm) |
| Max Vertical Wall Digging Depth | 19.3 ft in (5880 mm) |
| Max Digging Depth | 22 ft in (6705 mm) |
| Boom/Stick Option (Hex) 2 | Boom 21'3" (6470mm)/Stick 8'4" (2550mm) |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 35.88 ft in (10935 mm) |
| Max Cutting Height | 33.5 ft in (10210 mm) |
| Max Loading Height | 23.33 ft in (7110 mm) |
| Shipping Height Of Unit | 10.68 ft in (3255 mm) |
| Max Reach Along Ground | 35.83 ft in (10920 mm) |
| Max Vertical Wall Digging Depth | 21.26 ft in (6480 mm) |
| Max Digging Depth | 24.22 ft in (7380 mm) |
| Boom/Stick Option (Hex) 3 | Boom 21'3" (6470mm)/Stick 10'5" (3185mm) |
Boom/Stick Option (Hex) 4
| Shipping Length Of Unit | 36.01 ft in (10975 mm) |
| Shipping Height Of Unit | 11.78 ft in (3590 mm) |
| Max Cutting Height | 34.62 ft in (10550 mm) |
| Max Loading Height | 24.58 ft in (7490 mm) |
| Max Reach Along Ground | 38.49 ft in (11730 mm) |
| Max Digging Depth | 26.84 ft in (8180 mm) |
| Max Vertical Wall Dig Depth | 23.89 ft in (7280 mm) |
| Boom/Stick Option (Hex) 4 | Boom 21'3" (6470mm)/Stick 13'2" (4020mm) |
Dimensions
| Ground Clearance | 1.65 ft in (500 mm) |
| Height To Top Of Cab | 10.27 ft in (3130 mm) |
| Width To Outside Of Tracks | 10.47 ft in (3190 mm) |
| Length Of Track On Ground | 13.23 ft in (4030 mm) |
| Tail Swing Radius | 10.83 ft in (3300 mm) |
| Removal Counterweight Clearance | 3.89 ft in (1185 mm) |
Undercarriage
| Track Gauge | 8.5 ft in (2590 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Ground Pressure | 8.5 psi (58.61 kPa) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | SAA6D108E |
| Gross Power | 232 hp (173 kw) |
| Power Measured @ | 2050 rpm |
| Displacement | 436.4 cu in (7.2 L) |
Operational
| Operating Weight | 69445.7 lb (31500 kg) |
| Fuel Capacity | 142.7 gal (540 L) |
| Hydraulic System Fluid Capacity | 54.2 gal (205 L) |
| Hydraulic System Relief Valve Pressure | 5050 psi (34818.5 kPa) |
| Hydraulic Pump Flow Capacity | 132.7 gal/min (502 L/min) |
Swing Mechanism
| Swing Speed | 10 rpm |
Buckets
| Reference Bucket Capacity | 1.8 yd3 (1.4 m3) |
| Minimum Bucket Capacity | 0.7 yd3 (0.6 m3) |
| Maximum Bucket Capacity | 2.4 yd3 (1.8 m3) |
