Liebherr R924 COMPACT TUNNEL LITRONIC
Browse All Liebherr or Hydraulic Excavator Models
Contents:
Dimensions
| Ground Clearance | 1.97 ft in (600 mm) |
| Height To Top Of Cab | 8.29 ft in (2525 mm) |
| Undercarriage Width | 16.64 ft in (5070 mm) |
| Upper Structure Clearance | 3.76 ft in (1145 mm) |
| Wheelbase | 147.64 in (3750 mm) |
Undercarriage
| Number Of Carrier Rollers Per Side | 8/2 |
| Max Travel Speed | 5.3 mph (8.53 km/h) |
| Drawbar Pull | 46760.26 lb (208 kN) |
Electrical System
| Engine Idling | Sensor controlled |
| Alternator | 24 V / 140 A |
| Voltage | 24V V |
| Batteries | 2 x 135 Ah / 12 V |
Engine
| Horsepower, Net-Iso 9249 | 173 hp (129 kw) |
| Emission Tier Level | Tier 4 Final |
| Exhaust Gas Recirculation (Egr) | DOC Deutz |
| Number Of Cylinders | 4 |
| Engine Model | D 934 S |
| Cooling System | water-cooled |
| Air Cleaner | Dry-type |
| Power Measured @ | 1800 rpm |
| Displacement | 388.2 cu in (6.4 L) |
| Aspiration | Turbo-charged and after-coolerreduced emissions |
| Bore | 4.9 in (122 mm) |
| Stroke | 5.4 in (136 mm) |
Capacities
| Hydraulic Oil Tank | 38.9 gal (147 L) |
| Fuel Tank | 91.2 gal (345 L) |
| Hydraulic System | 95.2 gal (360 L) |
Operational
| Operating Weight | 55071.5 lb (24980 kg) |
Swing Mechanism
| Swing Speed | 12.7 rpm |
| Swing Torque | 51.8 lb ft (70.2 Nm) |
Buckets
| Minimum Bucket Capacity | 4.6 yd3 (3.5 m3) |
| Maximum Bucket Capacity | 5.3 yd3 (4 m3) |
Hydraulic System
| Maxpumpflow | 113.1 gal/min (428 L/min) |
