Case 480C
Browse All Case or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 8.27 ft in (2520 mm) |
| Reach From Swivel - Std | 15.59 ft in (4750 mm) |
| Dig Depth - Std | 11.98 ft in (3650 mm) |
| Bucket Dig Force - Ext | 6192 lb (2808.65 kg) |
| Dig Depth - Ext | 15 ft in (4570 mm) |
| Reach From Swivel - Ext | 18.41 ft in (5610 mm) |
| Bucket Dig Force - Std | 6383 lb (2895.29 kg) |
| Load Height - Ext | 8.67 ft in (2640 mm) |
Dimensions
| Transport Length | 10.5 ft in (3200 mm) |
| Transport Width | 6.67 ft in (2030 mm) |
| Wheelbase | 6.67 ft in (2030 mm) |
| Ground Clearance | 0.89 ft in (270 mm) |
| Shipping Weight | 5282.28 lb (2396 kg) |
| Front Wheel Tread Width | 61.82 in (1570 mm) |
| Height To Top Of Suspended Cab | 8.5 ft in (2590 mm) |
| Rear Tread Range | 65.75 in (1670 mm) |
Loader
| Clearance At Max Dump Height | 8.57 ft in (2610 mm) |
| Reach At Max Dump Height | 2.24 ft in (680 mm) |
| Lift Capacity At Full Height | 3000 lb (1360.78 kg) |
| Bucket Width | 73.63 in (1870 mm) |
| Bucket Breakout Force | 5700 lb (25.36 kN) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | J.I. Case |
| Engine Model | G188D |
| Net Power | 43 hp (32.1 kw) |
| Gross Power | 48 hp (35.8 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 189.2 cu in (3.1 L) |
| Bore | 3.9 in (97 mm) |
| Stroke | 4.2 in (105 mm) |
Operational
| Fuel Capacity | 22 gal (83.3 L) |
| Max Weight | 10757 lb (4879.3 kg) |
| Hydraulic System Fluid Capacity | 12 gal (45.5 L) |
| Oil System Fluid Capacity | 1.8 gal (6.6 L) |
| Cooling System Fluid Capacity | 5.3 gal (19.9 L) |
| Tire Size Front - 2wd / 4wd | 7.50x16 |
| Rear Tires Size 2wd/4wd | 14.9x24 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 42 amps |
Transmission
| Number Of Forward Gears | 8 |
| Number Of Reverse Gears | 8 |
| Max Speed - Forward | 20.4 mph (32.7 km/h) |
| Max Speed Reverse | 25 mph (40.2 km/h) |
