Caterpillar 438D
Browse All Caterpillar or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 12.18 ft in (3712 mm) |
| Reach From Swivel - Std | 18.5 ft in (5637 mm) |
| Dig Depth - Std | 15.93 ft in (4854 mm) |
| Reach At Load Height - Std | 5.72 ft in (1742 mm) |
| Bucket Dig Force - Std | 14710 lb (6672.35 kg) |
| Bucket Dig Force - Ext | 14580 lb (6613.38 kg) |
| Reach From Swivel - Ext | 21.87 ft in (6664 mm) |
| Dig Depth - Ext | 19.34 ft in (5894 mm) |
| Reach At Load Height - Ext | 9.02 ft in (2747 mm) |
| Load Height - Ext | 14.03 ft in (4274 mm) |
Dimensions
| Transport Length | 18.9 ft in (5760 mm) |
| Transport Width | 7.87 ft in (2396 mm) |
| Transport Height | 12.28 ft in (3740 mm) |
| Wheelbase | 6.89 ft in (2100 mm) |
| Ground Clearance | 1.05 ft in (320 mm) |
| Height To Top Of Suspended Cab | 9.52 ft in (2900 mm) |
Loader
| Clearance At Max Dump Height | 8.58 ft in (2613 mm) |
| Reach At Max Dump Height | 2.51 ft in (764 mm) |
| Dig Depth | 3.04 in (77 mm) |
| Lift Capacity At Full Height | 7469.27 lb (3388 kg) |
| Bucket Capacity | 1.31 yd3 (1 m3) |
| Bucket Width | 94.34 in (2396 mm) |
| Bucket Breakout Force | 11285.41 lb (50.2 kN) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2236 |
| Engine Model | 3054T |
| Net Power | 94 hp (70.1 kw) |
| Gross Power | 98 hp (73.1 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 244.1 cu in (4 L) |
Operational
| Fuel Capacity | 33.9 gal (128 L) |
| Operating Weight 4wd | 17081.5 lb (7748 kg) |
| Turning Radius | 17.8 ft in (5400 mm) |
| Tire Size Front - 2wd / 4wd | 12.5/80x18,10PR |
| Rear Tires Size 2wd/4wd | 16.9x28,10PR |
Transmission
| Transmission Type | power shuttle |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 19.8 mph (31.8 km/h) |
| Max Speed Reverse | 19.8 mph (31.8 km/h) |
Hydraulic
| Pump Type | LSPC, closed center |
| Pump Flow Capacity | 43.1 gal/min (163 L/min) |
| Relief Valve Pressure | 3306.9 psi (22800 kPa) |
