Hitachi ZX260F-6
Browse All Hitachi or Log Loader Models
Contents:
Boom/Stick Option (Lgl) 1
| Max Height | 34.11 ft in (10396.73 mm) |
| Max Reach At Ground Level | 32.6 ft in (9.94 m) |
| Max Depth Below Ground | 20.6 ft in (6278.88 mm) |
| Tail Swing Radius | 10.4 ft in (3.17 m) |
| Maximum Reach | 33.4 ft in (10.19 m) |
| Minimum Swing Radius | 10.7 ft in (3.27 m) |
| Maximum Log-Level Height | 26.1 ft in (7.96 m) |
Dimensions
| Ground Clearance | 2.33 ft in (710 mm) |
| Height To Top Of Cab | 12.6 ft in (3840 mm) |
| Undercarriage Width | 10.93 ft in (3330 mm) |
| Counterweight Clearance | 4.6 ft in (1400 mm) |
| Undercarriage Overall Length | 15.42 ft in (4700 mm) |
| Center To Center Idler To Sprocket | 8.6 ft in (2620 mm) |
| Overall Length | 33.34 ft in (10160 mm) |
| Track Shoe Width | 2.33 ft in (710 mm) |
Undercarriage
| Number Of Carrier Rollers Per Side | 2 |
| Ground Pressure | 8.92 psi (61.5 kPa) |
Engine
| Emissions Certification | EPA Final Tier 4 / EU Stage IV |
| Number Of Cylinders | 4 |
| Power Boost | 50958.9 hp (38000 kw) |
| Off-Level Capacity | 70 % |
| Engine Model | Isuzu 4HK1 |
| Net Power | 177.1 hp (132 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 316.8 cu in (5.2 L) |
| Aspiration | Turbocharged, air-to-air charge-air cooler |
| Oil Filter | Full-flow spin-on filter |
| Fan Drive Type | High efficiency direct-driven, suction-type fan and cool-on-demand hydraulic-driven, suction-type fan with remote-mounted drive for hydraulic oil cooler |
Operational
| Travel Speed, Low Range | 1.9 mph (2.9 km/h) |
| Travel Speed, High Range | 3 mph (4.7 km/h) |
| Def Tank Capacity | 18.5 gal (70 L) |
| Operating Weight | 72413.1 lb (32846 kg) |
| Fuel Capacity | 211.4 gal (800 L) |
| Cooling System Fluid Capacity | 9 gal (34 L) |
| Hydraulic System Fluid Capacity | 39 gal (147.6 L) |
| Operating Voltage | 24 V |
| Drawbar Pull | 56074.6 lb (25435 kg) |
| Alternator Supplied Amperage | 130 amps |
Swing Mechanism
| Swing Speed | 10.6 rpm |
| Swing Torque | 79560 lb ft (107868.9 Nm) |
Hydraulic
| Pump Type | Open center, pilot operated |
| Pump Flow Capacity | 65.6 gal/min (248 L/min) |
