Doosan DX225MH-3
Browse All Doosan or Material Handler Models
Contents:
Boom/Stick Option (Mat) 1
| Max Height | 40 ft in (12192 mm) |
| Max Reach Along Ground | 35.5 ft in (10820.4 mm) |
| Boom/Stick Option (Mat) 1 | Boom - 21.33 ft / Arm - 14.76 ft |
Dimensions
| Shipping Length | 31.1 ft in (9479.29 mm) |
| Undercarriage Width | 9.9 ft in (3017.52 mm) |
| Shipping Height | 9.1 ft in (2773.68 mm) |
| Height To Top Of Cab - Fixed Riser | 9.9 ft in (3017.52 mm) |
Engine
| Emission Tier Level | IT4 |
| Gross Power | 166.3 hp (124.1 kw) |
| Net Power | 162.3 hp (121.1 kw) |
| Displacement | 114.7 cu in (1.9 L) |
Operational
| Operating Weight W/O Attachment | 60848 lb (27600.2 kg) |
Swing Mechanism
| Swing Speed | 10.9 rpm |
| Swing Torque | 60757 lb ft (82375.5 Nm) |
Transmission
| Max Speed | 3.5 mph (5.6 km/h) |
Track Undercarriage
| Track Gauge | 7.1 ft in (2164.1 mm) |
| Number Of Shoes Per Side | 2 |
| Length Of Track On Ground | 14.7 ft in (4480.6 mm) |
Hydraulic
| Pump Capacity | 54.6 gal/min (206.5 L/min) |
| Relief Pressure | 4786.3 psi (33000.1 kPa) |
