Liebherr LH150M PORT LITRONIC
Browse All Liebherr or Material Handler Models
Contents:
Dimensions
| Wheelbase | 24.3 ft in (7406.64 mm) |
| Ground Clearance | 26.3 in (668.02 mm) |
| Undercarriage Width | 21.2 ft in (6461.76 mm) |
| Height To Top Of Cab | 15.6 in (396.24 mm) |
| Upper Structure Ground Clearance | 6.5 ft in (1981.2 mm) |
Engine
| Emission Tier Level | Tier 4f |
| Battery | 4 x 180 Ah/12 V |
| Number Of Cylinders | 8 |
| Engine Model | D9508 |
| Gross Power | 536 hp (399.7 kw) |
| Air Cleaner | dry-type air cleaner with pre-cleaner, primary and safety elements |
| Net Power | 543 hp (405 kw) |
| Power Measured @ | 1700 rpm |
| Displacement | 60175.6 cu in (986.1 L) |
| Bore | 5 in (127 mm) |
| Stroke | 6.2 in (157.5 mm) |
| Alternator | 180 amps |
Operational
| Urea Tank | 48 gal (181.7 L) |
| Fuel Capacity | 740 gal (2801.3 L) |
| Hydraulic Fluid Capacity | 328 gal (1241.7 L) |
| Hydraulic System Fluid Capacity | 502 gal (1900.3 L) |
Swing Mechanism
| Swing Speed | 5.5 rpm |
| Swing Torque | 191766 lb ft (259999.8 Nm) |
Hydraulic
| Pump Type | 4 Liebherr axial piston variable displacement pumps |
| Pump Capacity | 252 gal/min (954 L/min) |
| Relief Pressure | 5076 psi (34997.8 kPa) |
Brakes
| Service Brake | two circuit travel brake system with accumulator |
