Vermeer CX254
Browse All Vermeer or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Height Of Unit | 8.24 ft in (2510 mm) |
| Max Cutting Height | 17.29 ft in (5270 mm) |
| Max Loading Height | 13.16 ft in (4010 mm) |
| Max Reach Along Ground | 19 ft in (5790 mm) |
| Max Vertical Wall Digging Depth | 8.93 ft in (2720 mm) |
| Max Digging Depth | 11.85 ft in (3610 mm) |
| Boom/Stick Option (Hex) 1 | Boom / Stick |
Dimensions
| Width To Outside Of Tracks | 6.17 ft in (1880 mm) |
| Length Of Track On Ground | 8.01 ft in (2440 mm) |
| Ground Clearance | 2.17 ft in (660 mm) |
| Height To Top Of Cab | 8.24 ft in (2510 mm) |
| Tail Swing Radius | 4.5 ft in (1370 mm) |
Undercarriage
| Shoe Size | 16.15 in (410 mm) |
| Track Gauge | 4.83 ft in (1470 mm) |
| Max Travel Speed | 3.24 mph (5.2 km/h) |
| Ground Pressure | 4 psi (27.58 kPa) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2334 |
| Engine Model | V2003-T Diesel |
| Gross Power | 52 hp (38.8 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 122 cu in (2 L) |
Operational
| Operating Weight | 11223.8 lb (5091 kg) |
| Fuel Capacity | 17.2 gal (65.1 L) |
| Hydraulic System Fluid Capacity | 21.9 gal (82.9 L) |
| Hydraulic Pump Flow Capacity | 26.4 gal/min (99.9 L/min) |
