JCB 8008 CTS
Browse All JCB or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Reach Along Ground | 10.21 ft in (3110 mm) |
| Max Digging Height | 9.32 ft in (2840 mm) |
| Max.Dumping Height | 6.5 ft in (1980 mm) |
| Maximum Digging Depth – Dozer Up | 5.51 ft in (1679 mm) |
| Maximum Vertical Wallcut Depth | 5.55 ft in (1690 mm) |
Dimensions
| Tail Swing Radius | 2.63 ft in (800 mm) |
| Width Over Tracks | 2.3 ft in (700 mm) |
| Overall Height | 7.58 ft in (2310 mm) |
| Overall Length | 8.8 ft in (2682 mm) |
| Undercarriage Overall Length | 3.83 ft in (1165 mm) |
Undercarriage
| Track Tension | Grease |
| Tractive Effort | 55.12 lb (25 kg) |
| Drawbar Pull | 1742.27 lb (7.75 kN) |
| Number Of Track Rollers Per Side | 3 |
Engine
| Starter Motor | 1.2 KW |
| Engine Model | 403D-07 |
| Gross Power | 12.1 hp (9 kw) |
| Cooling System | Water cooled |
| Power Measured @ | 1800 rpm |
| Displacement | 46500.2 cu in (762 L) |
| Alternator | 15 amps |
Operational
| Operating Weight | 2447.2 lb (1110 kg) |
| Fuel Capacity | 3.1 gal (11.5 L) |
| Hydraulic System Fluid Capacity | 5.6 gal (21 L) |
| Engine Oil Capacity | 0.8 gal (3 L) |
| Water Spray System Fluid Capacity | 0.7 gal (2.6 L) |
| Hydraulic Pump Flow Capacity | 4.3 gal/min (16 L/min) |
Performance
| Gradeability | 130 % |
Hydraulic System
| Nominal Output | 29.7 gal/min (112.2 L/min) |
| Slew Main Relief | 90 lpm |
| Excavator/Track Main Relief | 170 bar |
| Auxiliary Hydraulic Flow | 6 gal/min (22.4 L/min) |
| Pump Type | 2 section gear |
Boom
| Boom Swing Left | 70 degrees |
| Boom Swing Right | 70 degrees |
| Bucket Rotation | 191 degrees |
| Bucket Tearout | 2090.8 lb (9.3 kN) |
| Dipper Tearout | 1034.2 lb (4.6 kN) |
