Airman EW160B
Browse All Airman or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Max Cutting Height | 28.88 ft in (8800 mm) |
| Max Reach Along Ground | 27.24 ft in (8300 mm) |
| Max Vertical Wall Dig Depth | 14.11 ft in (4300 mm) |
| Max Digging Depth | 16.74 ft in (5100 mm) |
Dimensions
| Wheelbase | 8.54 ft in (2600 mm) |
| Overall Width | 8.34 in (2540 mm) |
| Ground Clearance | 1.07 ft in (325 mm) |
| Overall Width - Outriggers Down | 12.87 ft in (3920 mm) |
| Height To Top Of Cab | 10.21 ft in (3110 mm) |
Engine
| Engine Make | 2244 |
| Engine Model | D6D EJE2 |
| Gross Power | 110 hp (82.1 kw) |
| Net Power | 103 hp (76.9 kw) |
| Displacement | 347.9 cu in (5.7 L) |
| Net Torque | 438.9 lb ft (595 Nm) |
| Aspiration | Turbocharged |
Operational
| Fuel Capacity | 250 gal (946.4 L) |
| Cooling System Fluid Capacity | 22 gal (83.3 L) |
| Engine Oil Capacity | 25 gal (94.7 L) |
| Front Diff Fluid Capacity | 2.3 gal (8.5 L) |
| Rear Diff Fluid Capacity | 3 gal (11 L) |
| Hydraulic System Fluid Capacity | 68.7 gal (260 L) |
| Operational Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Hydraulic Pump Type | Axial Piston Pump |
| Hydraulic Pump Flow Capacity | 63.5 gal/min (240 L/min) |
Swing Mechanism
| Swing Speed | 9.5 rpm |
Transmission
| Transmission Type | Powershift |
| Max Travel Speed | 21.8 mph (35 km/h) |
