Caterpillar 212
Browse All Caterpillar or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Shipping Length Of Unit | 26.12 ft in (7960 mm) |
| Shipping Height Of Unit | 10.33 ft in (3148 mm) |
| Max Cutting Height | 23.12 ft in (7045 mm) |
| Max Loading Height | 16.15 ft in (4920 mm) |
| Max Reach Along Ground | 25.25 ft in (7695 mm) |
| Max Vertical Wall Dig Depth | 8.99 ft in (2740 mm) |
| Max Digging Depth | 15.7 ft in (4785 mm) |
| Boom/Stick Option (Mex) 1 | One-Piece Boom/Stick 5'3" (1600mm) |
Boom/Stick Option (Mex) 2
| Shipping Length Of Unit | 26.25 ft in (8000 mm) |
| Shipping Height Of Unit | 10.33 ft in (3148 mm) |
| Max Cutting Height | 23.74 ft in (7235 mm) |
| Max Loading Height | 16.77 ft in (5110 mm) |
| Max Reach Along Ground | 27.37 ft in (8340 mm) |
| Max Vertical Wall Dig Depth | 11.11 ft in (3385 mm) |
| Max Digging Depth | 17.98 ft in (5480 mm) |
| Boom/Stick Option (Mex) 2 | One-Piece Boom/Stick 7'6.5" (2300mm) |
Boom/Stick Option (Mex) 3
| Shipping Height Of Unit | 10.33 ft in (3148 mm) |
| Shipping Length Of Unit | 26.19 ft in (7980 mm) |
| Max Cutting Height | 23.15 ft in (7055 mm) |
| Max Loading Height | 16.44 ft in (5010 mm) |
| Max Reach Along Ground | 28.56 ft in (8705 mm) |
| Max Vertical Wall Dig Depth | 11.32 ft in (3450 mm) |
| Max Digging Depth | 19.59 ft in (5970 mm) |
| Boom/Stick Option (Mex) 3 | One-Piece Boom/Stick 9'2" (2800mm) |
Boom/Stick Option (Mex) 4
| Shipping Height Of Unit | 10.33 ft in (3148 mm) |
| Shipping Length Of Unit | 26.12 ft in (7960 mm) |
| Max Cutting Height | 23.12 ft in (7045 mm) |
| Max Loading Height | 16.15 ft in (4920 mm) |
| Max Reach Along Ground | 25.25 ft in (7695 mm) |
| Max Vertical Wall Dig Depth | 8.99 ft in (2740 mm) |
| Max Digging Depth | 15.7 ft in (4785 mm) |
| Boom/Stick Option (Mex) 4 | Two-Piece Boom/Stick 5'3" (1600mm) |
Dimensions
| Wheelbase | 8.21 ft in (2500 mm) |
| Tail Swing Radius | 6.89 ft in (2100 mm) |
| Overall Width | 8.17 in (2490 mm) |
| Ground Clearance | 1.2 ft in (365 mm) |
| Overall Width - Outriggers Down | 11.98 ft in (3650 mm) |
| Height To Top Of Cab | 10.33 ft in (3148 mm) |
| Upper Structure Clearance | 4.09 ft in (1245 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | T4.236 |
| Net Power | 94 hp (70.1 kw) |
| Power Measured @ | 2150 rpm |
| Displacement | 235.6 cu in (3.9 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 28290 lb (12832.2 kg) |
| Fuel Capacity | 64.8 gal (245 L) |
| Cooling System Fluid Capacity | 8 gal (30 L) |
| Engine Oil Capacity | 2.5 gal (9.4 L) |
| Front Diff Fluid Capacity | 2.6 gal (9.5 L) |
| Rear Diff Fluid Capacity | 4 gal (15 L) |
| Hydraulic System Fluid Capacity | 87.2 gal (330 L) |
| Operational Voltage | 24 V |
| Hydraulic System Relief Valve Pressure | 4351.2 psi (30000 kPa) |
| Hydraulic Pump Flow Capacity | 57.1 gal/min (216 L/min) |
| Oscillating Axle Angle | 19 degrees |
| Max Steering Angle | 35 degrees |
| Tire Size | Dual 10.00-20 |
Transmission
| Transmission Type | Fully hydrostatic, variable displacement piston motor |
| Max Travel Speed | 12.4 mph (20 km/h) |
Buckets
| Reference Bucket Capacity | 0.8 yd3 (0.6 m3) |
| Minimum Bucket Capacity | 0.4 yd3 (0.3 m3) |
| Maximum Bucket Capacity | 1.3 yd3 (1 m3) |
