Caterpillar 214B FT
Browse All Caterpillar or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Max Cutting Height | 27.53 ft in (8390 mm) |
| Max Loading Height | 18.74 ft in (5710 mm) |
| Max Reach Along Ground | 28.02 ft in (8540 mm) |
| Max Vertical Wall Dig Depth | 11.06 ft in (3370 mm) |
| Max Digging Depth | 16.47 ft in (5020 mm) |
| Boom/Stick Option (Mex) 1 | Stick 5'11" (1800mm) |
Boom/Stick Option (Mex) 2
| Max Cutting Height | 28.35 ft in (8640 mm) |
| Max Loading Height | 19.59 ft in (5970 mm) |
| Max Reach Along Ground | 29.63 ft in (9030 mm) |
| Max Vertical Wall Dig Depth | 12.01 ft in (3660 mm) |
| Max Digging Depth | 18.12 ft in (5520 mm) |
| Boom/Stick Option (Mex) 2 | Stick 7'7" (2300mm) |
Boom/Stick Option (Mex) 3
| Max Cutting Height | 27.99 ft in (8530 mm) |
| Max Loading Height | 19.53 ft in (5950 mm) |
| Max Reach Along Ground | 30.84 ft in (9400 mm) |
| Max Vertical Wall Dig Depth | 11.75 ft in (3580 mm) |
| Max Digging Depth | 19.69 ft in (6000 mm) |
| Boom/Stick Option (Mex) 3 | Stick 9'2" (2800mm) |
Boom/Stick Option (Mex) 4
| Max Cutting Height | 29.76 ft in (9070 mm) |
| Max Loading Height | 21.3 ft in (6490 mm) |
| Max Reach Along Ground | 34.65 ft in (10560 mm) |
| Max Vertical Wall Dig Depth | 15.13 ft in (4610 mm) |
| Max Digging Depth | 23.63 ft in (7200 mm) |
| Boom/Stick Option (Mex) 4 | Stick 13'2" (4000mm) |
Dimensions
| Wheelbase | 8.54 ft in (2600 mm) |
| Overall Width | 8.21 in (2500 mm) |
| Ground Clearance | 1.12 ft in (340 mm) |
| Overall Width - Outriggers Down | 11.98 ft in (3650 mm) |
| Height To Top Of Cab | 10.47 ft in (3191 mm) |
| Upper Structure Clearance | 4.17 ft in (1270 mm) |
Engine
| Engine Make | 2236 |
| Engine Model | 3116 |
| Gross Power | 135 hp (100.7 kw) |
| Displacement | 402.8 cu in (6.6 L) |
Operational
| Fuel Capacity | 75.9 gal (287 L) |
| Hydraulic System Fluid Capacity | 87.2 gal (330 L) |
| Hydraulic System Relief Valve Pressure | 4640 psi (31991.7 kPa) |
| Hydraulic Pump Flow Capacity | 71.4 gal/min (270 L/min) |
| Tire Size | dual 10.00-20 12PR |
