Terex HML32
Browse All Terex or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Shipping Length Of Unit | 20.02 ft in (6100 mm) |
| Shipping Height Of Unit | 9.62 ft in (2930 mm) |
| Max Cutting Height | 24.61 ft in (7500 mm) |
| Max Loading Height | 17.72 ft in (5400 mm) |
| Max Vertical Wall Dig Depth | 11.55 ft in (3520 mm) |
| Max Digging Depth | 13.39 ft in (4080 mm) |
| Boom/Stick Option (Mex) 1 | two piece articulated boom |
Dimensions
| Wheelbase | 7.22 ft in (2200 mm) |
| Overall Width | 8.21 in (2500 mm) |
| Ground Clearance | 1.42 ft in (430 mm) |
| Height To Top Of Cab | 9.85 ft in (3000 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2349 |
| Engine Model | BF4 M 2012 |
| Net Power | 82 hp (61.2 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 247 cu in (4.1 L) |
| Aspiration | turbocharged |
Operational
| Fuel Capacity | 50.2 gal (190 L) |
| Operating Weight | 18959.8 lb (8600 kg) |
| Hydraulic System Fluid Capacity | 50.2 gal (190 L) |
| Operational Voltage | 12 V |
| Alternator Supplied Amperage | 850 amps |
| Hydraulic System Relief Valve Pressure | 4060 psi (27992.7 kPa) |
| Hydraulic Pump Type | axial piston |
| Hydraulic Pump Flow Capacity | 37.6 gal/min (142 L/min) |
| Oscillating Axle Angle | 11.5 degrees |
| Max Steering Angle | 32 degrees |
| Tire Size | 8.25-20, 14PR twin |
Swing Mechanism
| Swing Speed | 10 rpm |
Transmission
| Transmission Type | hydrostatic drive |
| Max Travel Speed | 12.4 mph (20 km/h) |
Buckets
| Reference Bucket Capacity | 0.4 yd3 (0.3 m3) |
| Minimum Bucket Capacity | 0.2 yd3 (0.1 m3) |
| Maximum Bucket Capacity | 0.6 yd3 (0.4 m3) |
